About Surgical Microscope

Surgical operating microscopes are essential tools in many medical fields, providing surgeons with magnified, well-lit views to perform complex operations with precision. Among these, the ENT surgical microscope is especially common, designed for delicate procedures involving the ear, nose, and throat. It features a distinctive 90-degree binocular head that allows surgeons a clear, direct line of sight. To suit various surgical needs, interchangeable objective lenses with focal lengths such as 175mm, 200mm, 250mm, 300mm, and 400mm can be easily attached to the optical head. This flexibility ensures the surgeon can adjust the working distance for optimal focus. Ophthalmic surgical microscopes are another key type, crafted specifically for eye surgeries. They offer precise optics tailored to the intricate requirements of ophthalmology, helping improve surgical outcomes. Each surgical microscope model is designed to enhance visibility, accuracy, and overall patient safety during critical procedures.

We Offer Cost Effective Models of Operating Microscopes (Floor Stand / Wall Mount / Table Clamp) For different applications viz Ophthalmology , ENT, Dental, Neuro, Plastic Surgery Etc. Also , Wet Lab Microscope Is Our Specialized Microscope. We are exporting our Operating Microscopes to more than 80 Countries world wide since last 18 years with proven track record.

Specifications Surgical Microscope


MICROSCOPE SECTION

  • Binocular Tubes:  Viewing Head : Binocular head with 45°
    inclined, 90° straight, or 0°–180° inclinable tubes
  • Eye Pieces: 12.5x W.F/16mm Dioptric Adjustment
  • Interpapillary Distance: Adjustable from 55 mm to 75 mm
  • Magnification System:3-Step Zoom: 7.5x, 12.5x, 20x
    OR 5-Step Zoom: 5x, 7.5x, 12.5x, 20x, 30x
  • Objective Lenses: Interchangeable
  • focal lengths: F = 200 / 250 / 300 / 400 mm
  • Working Distance: Working Distance: 200 mm, 250 mm,
    300 mm, 400 mm (Depending on objective used)

ILLUMINATION SECTION

  • Type: Optical light guide-based coaxial illumination
  • Light Source: Twin 24V / 250W
  • Halogen lamps / Optional: High-power LED (cool, energy- efficient, 50,000+ hours life)
  • Brightness Control: Continuous intensity adjustment for optimal lighting
  • Field Diameter: 70 mm uniform illuminated area
  • Integrated Filters:
    • Cobalt Blue
    • Red-Free (Green)
    • Heat Absorbing Filter
Focusing Mechanism:
  • Focusing Type: Motorized focusing system
  • Control: Hands-free foot switch operation for precision adjustment
Stand & Mounting Systems:
  • Floor Stand (mobile with locking castors)
  • Table Clamp (space-saving for lab settings)
  • Wall Mount (ergonomic fixed solution)
  • Vertical Arm Range : 400 mm counterbalanced vertical travel
  • Articulation: 3D adjustable arm for full range positioning and Maneuverability

Physical Dimensions:

  • Base Size: 600 mm × 550 mm
  • Total Height: 1550 mm
  • Weight: Approximately 60 kg (without accessories)
Electrical Requirements:
  • Power Supply: AC 220V / 110V, 50/60 Hz
  • Power Compatibility : Suitable for global use with standard voltage systems
Optical Accessories:
  • Beam Splitter (Single/Double Port)
  • Trinocular Head
  • Assistant Viewing Tube
  • Additional Objective Lenses
